HWATEKワイヤーおよびケーブルCO.、株式会社。
|
|
商品の詳細:
お支払配送条件:
|
| 定格電圧: | 150V | 定格温度: | 75°C |
|---|---|---|---|
| 導体材料: | 座礁する裸の銅 | 導体サイズ: | 16/0.254mm |
| 断熱材: | SR-PVC | 断熱の厚さ: | 0.23mm |
| 最小絶縁の厚さ: | 0.2mm | 外径: | 1.70±0.10mm |
| ジャケット素材: | PVC | ジャケットの厚さ: | 0.84mm |
| ミンジャケットの厚さ: | 0.66mm | ケーブル外径: | 7.6±0.30mm |
| 最大DC抵抗: | 21.4Ω/km | 抗張力: | ≥10.3MPa |
| 伸長: | ≥100% | 仕様: | HT2504809 |
| Construction | ||||
| Conductor | Bare copper starned | |||
| Cross section | 18AWG | |||
| Construction | 16/0.254mm | |||
| Strand Dia. | 1.18mm | |||
| Insulation | SR-PVC | |||
| Nom.Thickness | 0.23mm | |||
| Min.Thickness | 0.20mm | |||
| Insulation Dia. | 1.70±0.10mm | |||
| Insulation colour | 1.white 2.red 3.green 4.blue 5.yellow 6.brown 7.orange 8.black | |||
| Filler | optional | |||
| Assembly | 8Cx18AWG | |||
| Jacket | PVC | |||
| Nom.Thickness | 0.84mm | |||
| Min.Thickness | 0.66mm | |||
| Outer Dia. | 7.6±0.30mm | |||
| Colour | Per request | |||
Conductor Bared copper stranded
Cross section 18AWG
Construction 16/0.254mm
Elongation ≥100%
Aged condition 16/0.254mm
Insulation SR-PVC
Nom.Thickness 0.23 mm
Min.Thickness 0.2 mm
Insulation Dia.1.70±0.10mm
Insulation: :1.white 2.red 3.green 4.blue 5.yellow 6.brown 7.orange 8.black
Jacket: PVC
Reference standard:UL
Nom.Thickness 0.84 mm
Outer Dia. 0.66mm
Colour per request
Performance Characteristics
| Electric Performance | ||||||
| Rated Temperature | 75℃ | |||||
| Voltage rating | 150V | |||||
| Max.conductor DC resistance(20℃) | 21.4Ω/km | |||||
| Dielectric Strength AC | 2.0kV/1min | |||||
コンタクトパーソン: Jimmy Wang
電話番号: 17715039722
