HWATEKワイヤーおよびケーブルCO.、株式会社。
|
|
商品の詳細:
お支払配送条件:
|
| 導体: | 裸銅 | 絶縁: | エビ-2 |
|---|---|---|---|
| ジャケット: | EVM-1 | ケーブルの形状: | ラウンド |
| アプリケーション: | 産業用,消費用電気,医療用,電気自動車の充電,グリーンエネルギーなど | パッキング: | 巻き枠で詰められる |
| ボラッジ: | 1500V DC | 温度: | -40~90℃ |
| pn: | HT2504389 |
| Construction | |||||
| Conductor | |||||
| Cross section | A:2C×50.0mm2 | B:1C×25.0mm2 | C:3×2C×0.75mm2 | ||
| Construction | 1596/0.20mm | 798/0.20mm | 40/0.15mm +Tinsel+Kevlar |
||
| Strand Dia.(Ref.) | 9.90mm | 7.10mm | 1.30mm | ||
| Insulation | EVI-2 | ||||
| Nom.Thickness | 1.10mm | 1.00mm | 0.50mm | ||
| Min.Thickness | 0.90mm | 0.85mm | 0.35mm | ||
| Insulation Dia. | 12.40±0.40mm | 9.20±0.30mm | 2.35±0.15mm | ||
| Insulation colour | 1.red 2.black | B.yellow/green | C1.violet&white C2.orange&blue C3.gray&brown | ||
| Twisted pair | / | / | 4.7mm | ||
| Filler | PP rope | ||||
| Material | Non-woven | ||||
| Assembly | 2C×50.0mm2+1C×25.0mm2+6C×0.75mm2+W | ||||
| Jacket | EVM-1 | ||||
| Nom.Thickness | 2.20mm | ||||
| Min.Thickness | 1.77mm | ||||
| Outer Dia. | 32.00±1.00mm | ||||
| Colour | Black | ||||
Conductor Bared copper stranded
Cross section 2C×50.0mm2+1C×25.0mm2+6C×0.75mm2+W
Construction 1596/0.20mm ,798/0.20mm,40/0.15mm
Elongation ≥100%
Aged condition 110℃×168H
Insulation EVI-2
Nom.Thickness 1.00 mm
Min.Thickness 0.85 mm
Insulation Dia.12.40±0.40mm
nsulation: :red, black
Jacket EVM-1
Reference standard:IEC standard
Nom.Thickness 2.2 mm
Outer Dia. 32.00±1.00mm
Colour per request
UL758-E258652-20060111A-CertificateofCompliance(2)...
| Electric Performance | ||||||
| Rated Temperature | -40~90℃ | |||||
| Voltage rating | 1500V DC | |||||
| Max.conductor DC resistance(20℃) | A:0.423Ω/km B:0.848Ω/km C:27.4Ω/km | |||||
| Dielectric Strength | AC 3.5kV/5min | |||||
